打包箱和快拼箱都属于活动房屋的其中一种,这两种房屋在外观上看比较类似，但是在房屋结构和性能方面都是有差别的。那么济南打包箱和快拼箱究竟有哪些同与不同呢？我们一起来了解一下吧。

Both packing boxes and quick consolidation boxes belong to one type of prefabricated house. These two types of houses look similar in appearance, but have differences in structure and performance. So what are the similarities and differences between Jinan packing boxes and fast consolidation boxes? Let's take a look together.

打包箱

packing box

快拼式集装箱是在活动房基础上改良过来的，也叫做“快拼箱”，而“打包箱”是在出口型的集装箱房屋基础上演变过来的，是一款基于钢框架和轻质墙板结构体系的模块化建筑产品。

The quick combination container is an improved version of the prefabricated house, also known as the "quick combination container", while the "packaging box" evolved from the export type container house and is a modular building product based on a steel frame and lightweight wall panel structural system.

打包箱与快拼箱的共同点：

What are the commonalities between packing boxes and fast consolidation boxes

1.成熟的框架结构，房屋为整体结构，内有框架，墙体为彩钢复合板，稳定牢固，防震性能好，防水防火防腐，支持定制。

1. Mature frame structure, the house is an integral structure with a frame inside, and the walls are made of color steel composite panels, which are stable and firm, with good seismic performance, waterproof, fireproof, and anti-corrosion, and support customization.

2.盒子化体系，可以灵活组合、叠加，满足不同用途的空间需求。

2. Boxization system, which can be flexibly combined and stacked to meet the spatial needs of different purposes.

3.运输方便，尤其适合经常更换施工点的单位。

3. Convenient transportation, especially suitable for units that frequently change construction sites.

4.免烧焊设计，模块化安装施工，重量轻，拆装方便，速度快、效率高。

4. No welding design, modular installation and construction, light weight, convenient disassembly and assembly, fast speed, and high efficiency.

5.使用寿命10年-15年以上，抗震烈度8级、抗风11级，可重复循环使用。

5. The service life is 10-15 years or more, with a seismic intensity of 8 and a wind resistance of 11, and can be reused.

打包箱与快拼箱的不同点：

The difference between packing boxes and fast consolidation boxes:

1

one

快拼箱：通过紧固螺丝连接立柱和顶底梁。

Quick consolidation: Connect the columns and top and bottom beams with fastening screws.

打包箱：通过焊接来连接立柱和顶底梁。

Packaging box: Connect the column and top and bottom beams through welding.

2

two

快拼箱：立柱与上下吊头连接是用马车螺栓，外部可清晰直接显示，因露出的部分有一定的厚度，会导致两个箱子并列摆放中间会有约一公分的缝隙。

Quick consolidation: The column is connected to the upper and lower lifting heads using carriage bolts, which can be clearly and directly displayed on the outside. Due to the exposed part having a certain thickness, there will be a gap of about one centimeter between the two boxes placed side by side.

打包箱：立柱与上下吊头连接是用内六角螺栓，外观是看不到的，两个箱子并列摆放会很整齐。

Packaging box: The column is connected to the upper and lower lifting heads using hexagonal bolts, and the appearance is invisible. The two boxes will be placed neatly side by side.

3

three

快拼箱：下雨天积水可从箱子顶部四周的落水孔排除。

Quick consolidation: On rainy days, accumulated water can be drained from the drainage holes around the top of the box.

打包箱：内置落水管，积水可通过顶梁排水沟从四个内置落水管直接排到箱子底部。

Packaging box: With built-in downspouts, accumulated water can be directly discharged from the four built-in downspouts to the bottom of the box through the top beam drainage ditch.

打包箱和快拼箱都有着各自的优点，大家可以根据自己的实际要求进行选购。

Both packing boxes and fast consolidation boxes have their own advantages, and you can choose according to your actual requirements.

打包箱与快拼箱的共同点与不同点内容就讲解到这里了，希望能够给您好的帮助，您对此有怎样的疑惑或者需求，可以随时联系我们http://www.jnpkjzx.com了解！

That's all for the commonalities and differences between packing boxes and fast consolidation boxes. We hope to be of great help to you. If you have any doubts or needs regarding this, please feel free to contact us at any time http://www.jnpkjzx.com Understand!
